REST API Internals: A TypeScript & Node.js Field Guide

Caching, compression, OAuth 2.0, circuit breakers, and rate limiting — with production-ready TypeScript and Express code.

Packages used throughout this article:
npm install express compression helmet express-rate-limit opossum ioredis jsonwebtoken
npm install -D typescript @types/express @types/node @types/compression @types/jsonwebtoken ts-node

Table of Contents

1. HTTP Caching with ETags

2. Compression: Gzip vs Brotli

3. Content Negotiation & REST Verbs

4. OAuth 2.0 with JWT Validation

5. Circuit Breaker with Opossum

6. Rate Limiting Algorithms

00 — Setup

Project Structure

All examples assume a standard Express + TypeScript layout. Here's the base server config everything builds on:

TypeScriptsrc/server.ts — base setup

import express, { Application, Request, Response, NextFunction } from 'express';

import helmet from 'helmet';

const app: Application = express();

app.use(helmet()); // security headers out of the box

app.use(express.json()); // parse JSON bodies

app.use(express.urlencoded({ extended: true }));

// Global error handler — always last middleware

app.use((err: Error, req: Request, res: Response, _next: NextFunction) => {

console.error(err.stack);

res.status(500).json({ error: 'Internal server error' });

});

app.listen(3000, () => console.log('Server running on :3000'));

JSONtsconfig.json

{

"compilerOptions": {

"target": "ES2022",

"module": "commonjs",

"lib": ["ES2022"],

"outDir": "./dist",

"rootDir": "./src",

"strict": true,

"esModuleInterop": true,

"skipLibCheck": true

},

"include": ["src/**/*"]

}

01 — Performance

HTTP Caching with ETags

Caching is the highest-leverage performance tool in any REST API. When implemented correctly with validators, unchanged resources return a 304 Not Modified with no body — saving bandwidth and reducing database load entirely.

Cache-Control Directives — Decision Table

⚠️

no-cache ≠ "don't cache." It means "cache it, but always revalidate." Use no-store if you genuinely never want it cached. This is the most common REST caching mistake.

ETag Middleware in TypeScript

Express has built-in weak ETag generation (app.set('etag', 'weak')), but for real control — especially when you want to base ETags on entity version fields from your database — write your own middleware:

TypeScriptsrc/middleware/cacheControl.ts

import { Request, Response, NextFunction } from 'express';

import crypto from 'crypto';

interface CacheOptions {

maxAge?: number; // seconds

sMaxAge?: number; // CDN override

isPrivate?: boolean;

noStore?: boolean;

}

/**

* Generates a strong ETag from any serializable entity.

* Uses SHA-1 of JSON — fast, deterministic, no version field needed.

*/

export function generateETag(entity: unknown): string {

const hash = crypto

.createHash('sha1')

.update(JSON.stringify(entity))

.digest('hex')

.slice(0, 16);

return "${hash}";

}

/** Attach Cache-Control + ETag to the response and short-circuit on 304 */

export function withCache(options: CacheOptions = {}) {

return (_req: Request, res: Response, next: NextFunction) => {

if (options.noStore) {

res.setHeader('Cache-Control', 'no-store');

return next();

}

const parts: string[] = [];

if (options.isPrivate) parts.push('private');

else parts.push('public');

if (options.maxAge !== undefined) parts.push(max-age=${options.maxAge});

if (options.sMaxAge !== undefined) parts.push(s-maxage=${options.sMaxAge});

res.setHeader('Cache-Control', parts.join(', '));

next();

};

}

TypeScriptsrc/routes/employees.ts — ETag + 304 flow

import { Router, Request, Response } from 'express';

import { generateETag, withCache } from '../middleware/cacheControl';

import { findEmployeeById } from '../services/employeeService';

const router = Router();

router.get(

'/:id',

withCache({ maxAge: 300, sMaxAge: 600 }), // 5min browser, 10min CDN

async (req: Request, res: Response) => {

const employee = await findEmployeeById(Number(req.params.id));

if (!employee) {

return res.status(404).json({ error: 'Not found' });

}

const etag = generateETag(employee);

res.setHeader('ETag', etag);

res.setHeader('Last-Modified', new Date(employee.updatedAt).toUTCString());

// If client sent If-None-Match and it matches → 304, no body

if (req.headers['if-none-match'] === etag) {

return res.status(304).end();

}

// Check If-Modified-Since fallback

const ifModSince = req.headers['if-modified-since'];

if (ifModSince) {

const clientDate = new Date(ifModSince).getTime();

const resourceDate = new Date(employee.updatedAt).getTime();

if (clientDate >= resourceDate) return res.status(304).end();

}

res.status(200).json(employee);

}

);

export default router;

💡

Express's built-in app.set('etag', 'strong') auto-generates ETags from response bodies, but it requires the full response to be buffered first. The manual approach above short-circuits before any DB work if If-None-Match can be validated at the service layer using a version column.

02 — Bandwidth

Compression: Gzip vs Brotli

The Node compression package handles gzip and deflate transparently. For Brotli, you have two options: handle it at the Nginx/CDN layer (recommended for production), or use Node's built-in zlib.createBrotliCompress() for specific endpoints.

Gzip with the compression Middleware

TypeScriptsrc/middleware/compression.ts

import compression from 'compression';

import { Request, Response } from 'express';

// Apply gzip compression to responses > 1KB

export const gzipMiddleware = compression({

level: 6, // 0-9, 6 is the sweet spot (speed vs ratio)

threshold: 1024, // don't compress responses smaller than 1KB

filter: (req: Request, res: Response): boolean => {

// Never compress already-compressed formats

const type = res.getHeader('Content-Type') as string ?? '';

if (type.includes('image/') || type.includes('video/')) return false;

return compression.filter(req, res);

}

});

Brotli for a Specific Endpoint (Node built-in)

TypeScriptsrc/routes/export.ts — Brotli stream

import { Router, Request, Response } from 'express';

import zlib from 'zlib';

import { Readable } from 'stream';

const router = Router();

router.get('/data/export', async (req: Request, res: Response) => {

const acceptEncoding = req.headers['accept-encoding'] ?? '';

const data = await getLargeDataset(); // returns JSON string

const stream = Readable.from(data);

if (acceptEncoding.includes('br')) {

res.setHeader('Content-Encoding', 'br');

res.setHeader('Content-Type', 'application/json');

const brotli = zlib.createBrotliCompress({

params: { [zlib.constants.BROTLI_PARAM_QUALITY]: 4 } // 4 = fast for APIs

});

stream.pipe(brotli).pipe(res);

} else if (acceptEncoding.includes('gzip')) {

res.setHeader('Content-Encoding', 'gzip');

res.setHeader('Content-Type', 'application/json');

stream.pipe(zlib.createGzip()).pipe(res);

} else {

res.setHeader('Content-Type', 'application/json');

stream.pipe(res);

}

});

export default router;

🚫

Never compress encrypted or already-compressed payloads (JWTs, encrypted tokens, images, zip files). Compressing before encryption leaks information through size correlation — this is the CRIME/BREACH attack family.

03 — Interoperability

Content Negotiation & REST Verbs

Accept vs Content-Type — The Confusion Ends Here

Content Negotiation Middleware in TypeScript

TypeScriptsrc/middleware/negotiation.ts

import { Request, Response, NextFunction } from 'express';

const SUPPORTED_TYPES = ['application/json', 'application/xml'];

/** Reject requests with unsupported Content-Type (for POST/PUT/PATCH) */

export function requireJson(req: Request, res: Response, next: NextFunction) {

if (['POST', 'PUT', 'PATCH'].includes(req.method)) {

if (!req.is('application/json')) {

return res.status(415).json({

error: 'Unsupported Media Type',

supported: ['application/json']

});

}

}

next();

}

/** Respond in format the client requested via Accept header */

export function negotiate(<T>) {

return (res: Response, data: T): void => {

const accept = res.req.accepts(SUPPORTED_TYPES);

if (!accept) {

res.status(406).json({ error: 'Not Acceptable', supported: SUPPORTED_TYPES });

return;

}

if (accept === 'application/xml') {

res.type('xml').send(toXml(data)); // your XML serializer

} else {

res.json(data);

}

};

}

HTTP Verb Semantics — PUT vs PATCH

TypeScriptsrc/routes/employees.ts — PUT vs PATCH

interface Employee {

id: number;

name: string;

department: string;

salary: number;

location: string;

}

// PUT — caller must send the FULL employee or fields become undefined

router.put('/:id', async (req: Request, res: Response) => {

const employee: Employee = req.body; // TypeScript enforces all fields

if (!employee.name || !employee.department || !employee.salary) {

return res.status(400).json({ error: 'PUT requires all fields' });

}

const updated = await employeeService.replace(req.params.id, employee);

res.json(updated);

});

// PATCH — only send what changes; use Partial<T> for type safety

router.patch('/:id', async (req: Request, res: Response) => {

const delta: Partial<Employee> = req.body;

if (Object.keys(delta).length === 0) {

return res.status(400).json({ error: 'PATCH body must not be empty' });

}

const updated = await employeeService.merge(req.params.id, delta);

res.json(updated); // only salary changed → name/dept/location untouched

});

04 — Security

OAuth 2.0 with JWT Validation

🔑 Which Grant Type?

Machine-to-machine, no user?

Client Credentials — pass client_id + client_secret, get token

Server-side app (can store secrets)?

Authorization Code — most secure; secret never touches browser

SPA or mobile (can't store secrets)?

Authorization Code + PKCE — replaces client secret with code verifier

Implicit grant?

Deprecated in OAuth 2.1 — token in URL = exposed in logs, history, Referer

Authorization Code Flow

User clicks "Login with Google" App ──► GET https://accounts.google.com/oauth/authorize ?client_id=YOUR_ID &response_type=code &redirect_uri=https://yourapp.com/callback &scope=profile email &state=RANDOM_CSRF_TOKEN ← prevents CSRF — validate on return Google shows consent screen → User approves Google ──► REDIRECT https://yourapp.com/callback ?code=AUTH_CODE&state=RANDOM_CSRF_TOKEN App validates state, then server-to-server only: ──► POST https://oauth2.googleapis.com/token body: grant_type=authorization_code code=AUTH_CODE client_secret=YOUR_SECRET ← never exposed to browser Google ──► { access_token, refresh_token, expires_in }

JWT Validation Middleware

TypeScriptsrc/middleware/auth.ts

import { Request, Response, NextFunction } from 'express';

import jwt, { JwtPayload } from 'jsonwebtoken';

// Extend Express Request to carry the decoded token

declare global {

namespace Express {

interface Request {

user?: JwtPayload;

}

}

}

const JWT_SECRET = process.env.JWT_SECRET!; // RS256 public key in prod

export function authenticate(req: Request, res: Response, next: NextFunction) {

const authHeader = req.headers['authorization'];

if (!authHeader?.startsWith('Bearer ')) {

return res.status(401).json({ error: 'Missing or malformed Authorization header' });

}

const token = authHeader.slice(7);

try {

const payload = jwt.verify(token, JWT_SECRET) as JwtPayload;

req.user = payload;

next();

} catch (err) {

if (err instanceof jwt.TokenExpiredError) {

return res.status(401).json({ error: 'Token expired' });

}

return res.status(401).json({ error: 'Invalid token' });

}

}

/** Role-based authorization — use after authenticate() */

export function requireRole(...roles: string[]) {

return (req: Request, res: Response, next: NextFunction) => {

const userRole = req.user?.role as string;

if (!roles.includes(userRole)) {

// 403 = authenticated but not authorized (not 401)

return res.status(403).json({ error: 'Forbidden' });

}

next();

};

}

// Usage:

// router.delete('/:id', authenticate, requireRole('admin'), deleteEmployee);

🚫

Never put tokens in URL parameters. They appear in server logs, browser history, and Referer headers. Always use Authorization: Bearer <token>. Also: use RS256 (asymmetric) over HS256 in production — your resource server can verify tokens with the public key without ever seeing the signing secret.

Refresh Token Flow

TypeScriptsrc/routes/auth.ts — token refresh

router.post('/auth/refresh', async (req: Request, res: Response) => {

const { refreshToken } = req.body;

if (!refreshToken) {

return res.status(400).json({ error: 'refreshToken required' });

}

try {

// Verify the refresh token (use a separate secret)

const payload = jwt.verify(refreshToken, process.env.REFRESH_SECRET!) as JwtPayload;

// Check it hasn't been revoked (Redis blocklist pattern)

const isRevoked = await tokenStore.isRevoked(payload.jti!);

if (isRevoked) return res.status(401).json({ error: 'Refresh token revoked' });

// Issue new access token (short-lived: 15 min)

const accessToken = jwt.sign(

{ sub: payload.sub, role: payload.role },

process.env.JWT_SECRET!,

{ expiresIn: '15m' }

);

res.json({ accessToken });

} catch {

res.status(401).json({ error: 'Invalid refresh token' });

}

});

05 — Resilience

Circuit Breaker with Opossum

In Node.js, the standard circuit breaker library is Opossum (the Netflix OSS equivalent of Hystrix for the JS ecosystem). It prevents cascading failures when a downstream service is slow or unavailable.

The Problem It Solves

Without circuit breaker — slow downstream cascades: Node server has 100 concurrent requests All 100 await paymentService.charge() ← hangs for 30s each Event loop is blocked by pending Promises → All other API routes: timeout / 503 With Opossum — circuit opens after threshold: First 5 failures within 10s → circuit OPENS Subsequent calls → fallback() fires immediately (no await) After 30s half-open → 1 probe request sent If probe succeeds → circuit CLOSES, normal flow resumes

TypeScriptsrc/services/circuitBreaker.ts

import CircuitBreaker from 'opossum';

interface PaymentRequest { amount: number; userId: string; }

interface PaymentResult { transactionId: string; status: string; }

/** The function we want to protect */

async function callPaymentService(req: PaymentRequest): Promise<PaymentResult> {

const response = await fetch('https://payments.internal/charge', {

method: 'POST',

body: JSON.stringify(req),

signal: AbortSignal.timeout(3000) // 3s hard timeout per call

});

if (!response.ok) throw new Error(Payment service: ${response.status});

return response.json();

}

const options = {

timeout: 3000, // call must complete in 3s or it's a failure

errorThresholdPercentage: 50,// open circuit if 50% of calls fail

resetTimeout: 30000, // try again after 30s (half-open)

volumeThreshold: 5, // need at least 5 calls before tripping

};

export const paymentBreaker = new CircuitBreaker(callPaymentService, options);

// Fallback: what to return when circuit is open

paymentBreaker.fallback((_req: PaymentRequest) => ({

transactionId: 'DEFERRED',

status: 'queued' // queue for retry later rather than hard fail

}));

// Observability hooks

paymentBreaker.on('open', () => metrics.increment('circuit.payment.open'));

paymentBreaker.on('halfOpen', () => metrics.increment('circuit.payment.halfOpen'));

paymentBreaker.on('close', () => metrics.increment('circuit.payment.close'));

TypeScriptsrc/routes/payments.ts — using the breaker

router.post('/payments', authenticate, async (req: Request, res: Response) => {

try {

// paymentBreaker.fire() wraps callPaymentService with circuit logic

const result = await paymentBreaker.fire(req.body);

const statusCode = result.status === 'queued' ? 202 : 201;

res.status(statusCode).json(result);

} catch (err) {

// Circuit is open AND no fallback — this shouldn't happen with fallback set

res.status(503).json({

error: 'Service temporarily unavailable',

retryAfter: 30

});

}

});

💡

Use AbortSignal.timeout(ms) (Node 17.3+) on every fetch call inside your protected function. Without it, the circuit breaker's timeout option fires but the underlying HTTP request keeps running, consuming memory and file descriptors.

06 — Stability

Rate Limiting Algorithms

express-rate-limit — In-Process (single instance)

TypeScriptsrc/middleware/rateLimiter.ts

import rateLimit, { RateLimitRequestHandler } from 'express-rate-limit';

import { Request, Response } from 'express';

/** General API rate limit: 100 req / 15 min per IP */

export const apiLimiter: RateLimitRequestHandler = rateLimit({

windowMs: 15 60 1000, // 15 minutes

max: 100,

standardHeaders: true, // sets RateLimit-* headers (RFC 6585)

legacyHeaders: false,

keyGenerator: (req: Request): string => {

// Use authenticated user ID when available, fall back to IP

return (req.user?.sub as string) ?? req.ip ?? 'unknown';

},

handler: (_req: Request, res: Response): void => {

res.status(429).json({

error: 'rate_limit_exceeded',

message: 'Too many requests. Please slow down.',

retryAfter: res.getHeader('RateLimit-Reset')

});

}

});

/** Strict login limiter: 5 attempts / 15 min (brute-force protection) */

export const loginLimiter = rateLimit({

windowMs: 15 60 1000,

max: 5,

skipSuccessfulRequests: true, // only count failed logins

standardHeaders: true,

legacyHeaders: false

});

// Usage in routes:

// app.use('/api/', apiLimiter);

// app.post('/auth/login', loginLimiter, loginHandler);

Redis-Backed Distributed Rate Limiter (multi-instance)

In-process rate limiters break in a load-balanced environment — each instance has its own counter, so a user can hit 100 req × N instances. Use Redis to share state:

TypeScriptsrc/middleware/distributedRateLimiter.ts

import { Request, Response, NextFunction } from 'express';

import Redis from 'ioredis';

const redis = new Redis(process.env.REDIS_URL!);

interface RateLimitConfig {

windowSeconds: number;

maxRequests: number;

keyPrefix: string;

}

/**

* Sliding window log rate limiter using Redis sorted sets.

* Accurate across distributed instances — no double-burst edge case.

*/

export function distributedRateLimit(config: RateLimitConfig) {

return async (req: Request, res: Response, next: NextFunction) => {

const key = ${config.keyPrefix}:${req.ip};

const now = Date.now();

const windowStart = now - config.windowSeconds * 1000;

// Atomic pipeline: remove old entries, add current, count, set expiry

const pipeline = redis.pipeline();

pipeline.zremrangebyscore(key, 0, windowStart); // prune expired

pipeline.zadd(key, now, ${now}-${Math.random()}); // add this request

pipeline.zcard(key); // count in window

pipeline.expire(key, config.windowSeconds); // auto-cleanup

const results = await pipeline.exec();

const count = results?.[2]?.[1] as number;

res.setHeader('X-RateLimit-Limit', config.maxRequests);

res.setHeader('X-RateLimit-Remaining', Math.max(0, config.maxRequests - count));

if (count > config.maxRequests) {

res.setHeader('Retry-After', config.windowSeconds);

return res.status(429).json({

error: 'rate_limit_exceeded',

retryAfter: config.windowSeconds

});

}

next();

};

}

// Usage:

// router.get('/search', distributedRateLimit({ windowSeconds: 60, maxRequests: 30, keyPrefix: 'search' }), searchHandler);

⚠️

Fixed Window edge case: With a 100 req/min limit, a client can send 100 requests at 11:59:59 and 100 more at 12:00:01 — 200 requests in 2 seconds, all within their limit. This can overwhelm your downstream. Sliding window eliminates this.

Always Return Retry-After on 429

HTTP ResponseCorrect 429 response

HTTP/1.1 429 Too Many Requests

Content-Type: application/json

Retry-After: 60

X-RateLimit-Limit: 100

X-RateLimit-Remaining: 0

X-RateLimit-Reset: 1719310000

{

"error": "rate_limit_exceeded",

"message": "100 requests per 15 minutes exceeded.",

"retryAfter": 60

}

Summary

Status Codes Developers Get Wrong

REST API Internals: TypeScript & Node.js Field Guide · June 2026 · Express · Node 20+ · TypeScript 5
